Print Method
| Direct Thermal |
Print Width
| 72 mm
|
Print Speed
| 200-300 mm's
|
Print Desity
| 576 dots/line (203 DPl)
|
Working Life
| Print Life: 150 km Cutter Life: 1.5 million times
|
Language
| English/Chinese (5/T) /apanese/Korean /Extended code page
|
Print Command
| ESC/POs command
|
Barcode Type | UPCA,UPC.E.CODE39, CODE93,CODABAR, CODE 128,ITF,EANBUAN8), EAN13UAN13), ORcode |
Bitmap Function
| Download bitmap, Roaster bitmap, Nv bitmap
|
Detection Function | Paper Detection, Temperature Detection, Cover Opening Detection. |
Print Interface | Standard:100M+USB Print interface Optional 1: 100M+ USB+MFI Optional 2: 100M+USB+Bluetooth |
Cashdrawer Interface | PIN 2.1. |
Receipt Buffer | 32K Bytes
|
Dimension | 205x140x120 mm
|
Weight | 860 g |
Environmental Requirements | Working:Temperature 0-50 ℃ Humidity: 20% RH~85% RH(No condensation) StorageTemperature:-20~60℃ Humidity: 5% RH~95% RH(No condensation)
|
Input Power | DC 24 V-1.5A OCP
|
Reliability | MCBF > 10 million |
