| Specification | BP5200DN | BP5200DW |
|---|---|---|
| Model | PT2AB1A-S1-01 | PT2AB1A-S1A-01 |
| Print speed | 42ppm(A4)/44ppm(Letter) | 42ppm(A4)/44ppm(Letter) |
| First print out time | ≤5.9s | ≤5.9s |
| Recommended monthly page volume | 750 to 4,000 pages | 750 to 4,000 pages |
| Printer language | PCL5e, PCL6, PS, GDI | PCL5e, PCL6, PS, GDI |
| Control panel | 2 line LCD | 2 line LCD |
| Processor speed | 1.2GHz | 1.2GHz |
| Memory | 1GB | 1GB |
| Duplex printing | Yes | Yes |
| Mobile printing capability | AirPrint, Mopria™ Print Service, APP print (iOS App/Android App) | AirPrint, Mopria™ Print Service, APP print (iOS App/Android App) |
| NFC function | No | Yes |
| Paper input tray | Standard: 250 Pages; Optional: 550 Pages (Max: 2); Multipurpose: 60 Pages | Standard: 250 Pages; Optional: 550 Pages (Max: 2); Multipurpose: 60 Pages |
| Paper output tray | 150 Pages | 150 Pages |
| Media weight | Input tray: 60~120g/㎡; Multipurpose tray: 60~200g/㎡; Optional tray: 60~120g/㎡ | Input tray: 60~120g/㎡; Multipurpose tray: 60~200g/㎡; Optional tray: 60~120g/㎡ |
| Product Dimensions (W*D*H) | 364*343*236mm | 364*343*236mm |
| Product weight (with cartridge) | 9.3kg | 9.3kg |
| Input voltage | 110V: AC100-127V, 50/60Hz, 12A; 220V: AC220-240V, 50/60Hz, 6.5A | 110V: AC100-127V, 50/60Hz, 12A; 220V: AC220-240V, 50/60Hz, 6.5A |
| Noise level | Print: ≤56dB(A); Ready: ≤30dB(A); Mute: ≤50dB(A) | Print: ≤56dB(A); Ready: ≤30dB(A); Mute: ≤50dB(A) |
| Power consumption | Print average: ≤650W; Ready: ≤8W; Sleep: ≤1.4W; Shutdown ≤0.5W | Print average: ≤650W; Ready: ≤8W; Sleep: ≤1.4W; Shutdown ≤0.5W |
| Interface | High-speed USB 2.0; IEEE 802.3 10/100/1000Base-Tx; Rear USB DEV (1) | High-speed USB 2.0; IEEE 802.3 10/100/1000Base-Tx; Rear USB DEV (1); Bluetooth |
| Consumable type | Toner Cartridge & Drum Unit | Toner Cartridge & Drum Unit |
| Starter cartridge | TL-*5220: 3,000 Pages | TL-*5220: 3,000 Pages |
| Starter drum unit | DL-*5220: 30,000 Pages | DL-*5220: 30,000 Pages |
| Standard cartridge | TL-*5220: 3,000 Pages; TL-*5220H: 6,000 Pages; TL-*5220X: 15,000 Pages | TL-*5220: 3,000 Pages; TL-*5220H: 6,000 Pages; TL-*5220X: 15,000 Pages |
